Radial Drill Machine

Weight

2800KG

Automatic Grade

Manual

Hole Diameter

0-25 mm,25-50 mm,50-100 mm

Max Speed (rpm)

1440

Automation Grade

Semi-Automatic

Warranty

1 year

Drilling Diameter

38MM

Brand

PATHAK

Model

PRD-25

PRD-32

PRD-38G

PRD-38G

Drilling capacity (in steel)

1"

11/4"

PRD-38G

PRD-38G

Max. Dist. from spindle center to column

21"

30"

30"

36"

Mini. Dist. from spindle center to column

9"

11"

11"

12"

Vertical travel of arm

27"

33"

36"

36"

Spindle travel

5"

6"

7"

7"

Spindle speeds

3

4

8

6

Range of spindle speeds

280-940

235-730

88-2600

190-520

Power required (R.P.M,) for simple drive

1 H.P.(960)

2 H.P.(960)

2 H.P.(1440)

3 H.P.(960)

Power required (R.P.M.) for elevating arm

-

-

1 H.P.(1440)

-

Spindle bore

M.T. No.2

M.T. No.3

M.T. No.4

M.T. No.4

Pillar Diameter

5"

7"

61/2"

Spindle diameter

11/2"

2"

21/2"

2%"

Work table

8" x 8" x 9"

9" x 9" x 8"

14" x 12" x 12"

15" x 15" x 12"

Working surface of base

18" x 19"

20" x 25"

32" x 24"

31" x 21"
